Bally Games FO-560-3 Service / Repair Manual (ORIGINAL):

Price: $35.00 each

Status: In Stock
(1 Available)

Order:



Part #: PM0697
Condition: Used (Original)
92 pages. Electronic pinball repair manual used by shop technicians. This manual covers most circuit boards and diagnostic procedures for 1977-1985 Bally electronic pinball games. Updated version with some additional, newer information from the previous year's edition, for the newer games. Also contains information on the Squawk & Talk sound/speech board, including theory of operation and diagnostic repair procedures. Use this manual if your game has sounds and speech (most games 1980-1985).

Used original manual in excellent condition. A few light smudges on covers. No handwriting noticed on inside pages on quick flip-through. Factory part # FO 560-3.

NOTE: No returns on Paperwork Items - all sales final.

NOTE: No warranty or returns on used items. Used items are sold as-is, and all sales are final.

  • Ask a question about this item

    Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
    BALLY: Baby Pac-Man, Black Jack, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Dolly Parton, Eight Ball, Eight Ball Deluxe, Eight Ball Deluxe Limited Edition, Elektra, Embryon, Evel Knievel, Fathom, Fireball Classic, Fireball II, Flash Gordon, Frontier, Future Spa, Goldball, Grand Slam, Granny and the Gators, Harlem Globetrotters, Hotdoggin', Kings of Steel, KISS, Lost World, Mata Hari, Medusa, Mr. & Mrs. Pac-Man, Mystic, Night Rider, Nitro Ground Shaker, Paragon, Playboy, Power Play, Rolling Stones, Silverball Mania, Six Million Dollar Man, Skateball, Space Invaders, Speakeasy, Speakeasy 4, Spectrum, Spy Hunter, Star Trek, Strikes and Spares, Supersonic, Vector, Viking, Voltan, Xenon, X's & O's
