World Cup (Williams) Schematics / Wiring Diagrams 5pgs (ORIGINAL - USED):

Price: $10.00
Status: In Stock
(1 Available)

Order:

Part #: PM0434
Condition: Used (Original)

Used original 5-page set of fold-out schematic wiring diagrams for Williams World Cup pinball. Each page folds out to 11x17 inches.

Includes the following pages:

Solid-state sound board diagram with part listing
Power supply schematic diagram
Power/transformer wiring schematic
Main cabinet wiring diagram
Playfield solenoid wiring diagram

Does not include any other schematics or wiring diagrams- this is the complete fold-out set for this game, as shipped from Williams.

Used item in very good condition. No handwriting on any pages. Staples have been removed from this set but all 5 pages are still together.

NOTE: No returns on Paperwork Items - all sales final.

NOTE: No warranty or returns on used items. Used items are sold as-is, and all sales are final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
WILLIAMS: World Cup
