Triple Strike pinball (Williams) Schematic Wiring Diagram:

Price: $20.00 each

Status: In Stock
Order:



Part #: PM0413
Condition: New (Reprint)
Fold-out wiring diagram for entire game. Includes diagrams of all circuits with listings of relays/coils/solenoids and part numbers. Reprint diagram in new condition.

NOTE: No returns on Paperwork Items - all sales final.

  • Ask a question about this item

    Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
    WILLIAMS: Triple Strike (pinball)
