Bally Theory of Operation Manual FO-601 (June 1978) (ORIGINAL - USED):

Price: $12.50 each

Status: In Stock
(1 Available)

Order:



Part #: PM0377
Condition: Used (Original)
Used original manual. 20 pages. Includes FO-601-1 supplement. Dated 1 June, 1978.

This manual provides an in-depth overview of low-level operation of the AS-2518-17 and AS-2518-35 MPU boards used in early Bally solid-state (SS) pinball games from 1977-1985. it discusses what goes on behind each of the LED flashes during game startup/self-test, game initialization, game play normal mode and CPU and display interrupts. Self-diagnostic test procedures and opearation of the solenoid driver module are also covered, and some IC parts listing information is also included. Great reference for any pinball owner trying his hand at low-level diagnosis and repair of MPU board issues.

Used original manual in good condition. Some stains on front and back covers. No handwriting on inside pages.

NOTE: No returns on Paperwork Items - all sales final.

NOTE: No warranty or returns on used items. Used items are sold as-is, and all sales are final.

  • Ask a question about this item

    Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
    BALLY: Baby Pac-Man, Black Jack, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Dolly Parton, Eight Ball, Eight Ball Deluxe, Eight Ball Deluxe Limited Edition, Elektra, Embryon, Evel Knievel, Fathom, Fireball Classic, Fireball II, Flash Gordon, Frontier, Future Spa, Goldball, Grand Slam, Granny and the Gators, Harlem Globetrotters, Hotdoggin', Kings of Steel, KISS, Lost World, Mata Hari, Medusa, Mr. & Mrs. Pac-Man, Mystic, Night Rider, Nitro Ground Shaker, Paragon, Playboy, Power Play, Rolling Stones, Silverball Mania, Six Million Dollar Man, Skateball, Space Invaders, Speakeasy, Speakeasy 4, Spectrum, Spy Hunter, Star Trek, Strikes and Spares, Supersonic, Vector, Viking, Voltan, Xenon, X's & O's
