South Park (Sega/Stern) Game Manual and Schematics (Reprint):

Price: $47.12 each
Status: In Stock

Order:

Part #: PM0351
Condition: New (Reprint)

142 pages. Includes info on game setup, operation, adjustments, settings, bookkeeping/audits, parts listings & diagrams, and electronic schematics & wiring diagrams. Reprint manual in new condition. Original factory part # 780-5071-00.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
SEGA/STERN: South Park
