Pharaoh (Williams) Game Manual & Schematics:

Price: $21.93 each

Status: In Stock
Order:



Part #: PM0298
Condition: New (Reprint)
25 pages. Game setup/operation info with fold-out wiring and circuit-board schematic diagrams. Reprint manual in new condition. Original factory part # 16P-504-101.

NOTE: No returns on Paperwork Items - all sales final.

  • Ask a question about this item

    Used In The Following Games:
    WILLIAMS: Pharaoh
