Middle Earth (Atari) Schematic Diagram Set (ORIGINAL):

Price: $12.50 set

Status: In Stock
(1 Available)

Order:



Part #: PM0268
Condition: Used (Original)
2 large fold-out wiring diagram sheets to go along with game manual for Atari Middle Earth pinball. Covers all wiring, switches, lamps, coils, and power supply in the game. Back side of sheet 2 has playfield layout diagram with lamp, switch, and solenoid locations (see additional image below). Each sheet measures 34 x 22 inches.

Used factory-original paperwork in excellent condition.

Additional Images:
Click to Enlarge



NOTE: No returns on Paperwork Items - all sales final.

NOTE: No warranty or returns on used items. Used items are sold as-is, and all sales are final.

  • Ask a question about this item

    Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
    ATARI: Middle Earth
