Black Jack (Electronic) (Bally) Game Manual w/ Schematics (Reprint) (SEE NOTE):

Price: $24.50 each

Status: In Stock
Order:



Part #: PM0267
Condition: New (Reprint)
40 pages. For electronic solid-state (SS) version of Bally Black Jack. Includes game operating/adjustment instructions, parts listing, diagnostics info, manual corrections amendment, and fold-out schematics/wiring diagrams. Original factory part # FO-583.

NOTE: Page 7 in the Black Jack manual is blank, from the factory. This is also the case in other early Bally solid-state manuals, including those for Mata Hari, Power Play, and Strikes and Spares. Index at front of manual lists page 7 as GAME FEATURE OPTIONS, but this information was never published or included in the manual on page 7, from the factory, and simply does not exist. It is not a reprint error or binding oversight- this is the way the manual was published from the factory in 1978. This missing information can instead be found on the paper cards stapled in the backbox, above the circuit boards. Please refer to those cards, in your game, for game feature option settings.

NOTE: No returns on Paperwork Items - all sales final.

  • Ask a question about this item

    Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
    BALLY: Black Jack (electronic)
