Laser Cue (Williams) Game Manual Set (2pcs) (Reprint):

Price: $39.00 set
Status: In Stock

Order:

Part #: PM0239
Condition: New (Reprint)

Buy together and save! Set of 2 manuals for Williams Laser Cue pinball: Instruction Manual and Drawing Set manual.

Instruction Manual is 12 pages and includes general game setup, operation, and adjustment information.

Drawing Set manual is 22 pages and includes fold-out wiring diagrams for circuit boards and playfield/cabinet/backbox wiring and some part listings.

Reprint manuals in new condition. Original factory part numbers 16-520-100 and 16-520-101, respectively.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
WILLIAMS: Laser Cue
