Jungle Lord (Williams) Game Manual and Schematics (Reprint) (SEE NOTE):

Price: $24.58 each
Status: In Stock

Order:

Part #: PM0228
Condition: New (Reprint)

24 pages. Includes game setup/operating info and fold-out schematics/wiring diagrams. Original factory part # 16P-503-101.

NOTE: This manual is a new reproduction copy of an original pre-owned manual which has some minor handwriting in a few spots on some pages.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
WILLIAMS: Jungle Lord
