Harley Davidson 1st Edition (Sega) Game Manual and Schematics (Reprint):
Price: $48.42 each
Status: In Stock
Part #: PM0192
Condition: New (Reprint)
|
|
|
154 pages. Covers Sega Harley Davidson pinball (1st edition). Can also be used with Sega / Stern 2nd and 3rd edition models as well. Includes game operating/adjustment instructions, parts listing & diagrams, adjustments/settings, and wiring / schematic diagrams. Reprint manual in new condition. Original factory part # 780-5067-01.
NOTE: No returns on Paperwork Items - all sales final.
Ask a question about this item
Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
SEGA: Harley Davidson (1st edition)
STERN: Harley Davidson (1st Edition), Harley Davidson (2nd edition), Harley Davidson (3rd edition)
|
