Dr. Dude (Bally) Game Manual and Schematics - System 11 Boardset Games (Reprint):

Price: $47.50 each

Status: In Stock
Order:



Part #: PM0118
Condition: New (Reprint)
For games with System 11 boardset (does not cover Dr. Dude games that have the WPC boardset). 132 pages. Includes game operating/adjustment instructions, parts listing, adjustments/settings, and game-specific wiring diagrams. Reprint manual in new condition. Original factory part # 16-2016-101.

NOTE: No returns on Paperwork Items - all sales final.

  • Ask a question about this item

    Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
    BALLY: Dr. Dude
