Turboboost Kicker Assembly (Data East) (SEE NOTES):

Price: $67.23 each
Status: In Stock
(3 Available)

Order:

Part #: 500-5304-00
Condition: New

Replacement Turbo Boost ball kicker assembly for some Data East games. Includes some new reproduction replacement parts, and substitute parts, that replace obsolete original parts which are no longer available (see listing and note below). Also replaces # 500-5304-01 (same thing).

Includes the following parts:

Kicker arm # 515-5350-00
Kicker arm pivot bracket # 515-5048-00
1/4-inch E-Clip (2) # ECLIP1/4
Coil 22-600 # 090-5023-0B (replaces obsolete # 090-5023-00)
Coil sleeve # 03-7066 (replaces obsolete # 260-0004-00)
Coil diode # 1N4004 (replaces original # 112-5001-00)
Coil plunger spring # 10-128 (replaces obsolete # 266-5000-00)
Coil mounting/plunger guide bracket # 535-5203-03 (replaces obsolete bracket # 535-5201-00)
Coil mounting/plunger guide bracket screws (2) # HWR02-090802
Coil mounting bracket # A-17808 (See note below. Replaces obsolete bracket # 515-5369-00 - used with plunger & link below to provide proper throw for kicker arm)
Coil plunger & link # A-8050-1 (longer replacement for original # 515-5338-00 (with # 545-5062-00 link) which makes up for shorter stop on replacement bracket # A-17808 to provide proper amount of throw for kicker arm)

NOTES:

This is a modern assembly that includes some new reproduction parts, and some parts that are substituted for original parts that are no longer available new or as reproductions. Some adjustment/repositioning of the kicker pivot bracket as well as the coil mounting bracket may be required due to slight differences between old and new parts, including possibly drilling new screw holes to mount these parts. Coil bracket includes 4 screw holes (replaces obsolete 3-hole bracket) so will require drilling new holes and adding a 4th screw (you can use our part # HWR02-030606, sold separately).
This part is used for the game(s) listed below. May not fit or work properly on other games not listed below.
Returned parts must be authorized with an RMA number, and are subject to a 10% restocking charge.
